MAKR24

Combined Materials:

Stationary Ring (Carbon/SiC/TC)
Rotary Ring (Ceramic/SiC/TC)
Secondary Seal (NBR/EPDM/Viton)
Spring and Punched Parts (Steel)

Working Conditions:

Pumps: Smal water pumps and Pipe pumps.
Temperature: -20oC~100oC
Pressure: =0.5Mpa
Speed: = 6 m/Sec
