Operational Conditions:

Temperature: -20oC to +120oC
Pressure: =1.0MPa
Speed: =15m/s


Stationary Ring: Ceramic (Alumina), Silicon Carbide Reaction Bonded, Silicon Carbide Sintered Pressureless, Ni-binder Tungsten Carbide Rotary Ring: Resin Impregnated Carbon Graphite (Furan), Antimony Impreg, Carbon Graphite, Silicon Carbide Sintered Pressureless, Silicon Carbide Reaction Bonded
Secondary Seal: Nitrile (NBR), Ethylene Propylene (EPDM), Fluorocarbon Rubber (Viton)Spring and Metal Parts: Stainless Steel, Stainless Steel


Clean Water, Sewage Water, Oil and other moderately corrosive fluids
