MAK471

Combined Materials:

Stationary Ring (Ceramic/SiC/TC)
Rotary Ring (Carbon/SiC/TC)
Secondary Seal (NBR/EPDM/Viton)
Spring and Punched Parts (Steel)

Working Conditions:

Pumps: Submersible pumps,
sewage pumps. Applied to
the muddy water, sewage
water or weakly corrosive fluids
with soild grains.
Temperature: -20oC~100oC
Pressure: =0.35Mpa
Speed: = 8 m/Sec
